KGQF-Series Aircraft Engine Starting Power Supply

KGQF-Series Aircraft Engine Starting Power Supply

Product Introduction:
The aircraft engine starting power supply adopts thyristor rectifier power supply, DSP microcomputer digital control technology and touch screen operation system. This engine power source is of fast output response speed and non overshoot. The output voltage is continuous and adjustable. As an engine starting power supply, the aircraft engine starting power supply is broadly used in delivery inspection of military aviation aircraft engine, aircraft repair plant, military aircraft, tank and armored car.

Main Technical Features of This Engine Power Source:
1. Main protection functions of the aircraft engine starting power supply include openphase, overvoltage, under voltage, quick fuse or fuse alarm protections of AC power supply, output over current and current limiting protections, output short circuit and instantaneous overload protections.
2. This engine power source can display, store and record working current and voltage and historical curves of current and voltage in time.

3. Aircraft engine starting power supply can be connected with computer through RS485 communication interface, or be stored by U disk then re-stored to computer, which is convenient to save customers' files.
4. This engine power source conforms to national military the standard of GJB181 aircaft electric power and GJB572 aircraft ground electric power characteristics, and the requirement of general electrical equipments.
5. For communication means, our company can provide CAN BUS, PROFIBUS, ETHERNET, RS485 and RS232 optical fiber communication to realize remote control or monitor of the aircraft engine starting power supply .
6. With DSP microcomputer digital instantaneous value of double closed loop control, the starting of master controller is stable and non-overshoot.
7. We can configure DC27-30V auxiliary DC control engine power source according to customers' requirements.

Main Specifications of Aircraft Engine Starting Power Supply:

Power Supply              3P AC380V, 400V, 450V, etc. frequency (50Hz)
Rated Output Voltage 24V, 28V, 30V, 48V, any voltage specification
Rated Output Current 300A, 400A, 500A, 800A, 1000A, 1200A, 1500A, 2000A, any current specification
Constant Voltage Control Accuracy ≤±1%
Operation Mode local or remote operation mode
Output Control Mode constant voltage output control mode
Rectifier Mode SCR 6-pulse rectifier

Chengdu General Rectifier Research Institute is a professional manufacturer and supplier of aircraft engine starting power supply in China. We also produce tank engine starting power supply and armored vehicle engine power source. Our products have been exported to USA, Germany, Australia, Singapore, India, Brazil, Iran, Vietnam, Kazakhstan and Malaysia, etc.
